Item # 9116
9116 - Multi-Range 150V/30A/1200W DC Power Supply
Item # 9116
9116 - Multi-Range 150V/30A/1200W DC Power Supply
- UM : EA
- Weight: 27.0000
Description: Any 9116 Series model can replace several supplies on your bench or in your rack.
For benchtop applications, this series provides a numerical keypad for direct data entry along with convenient cursors and analog style knobs to quickly make incremental voltage or current changes. Systems integrators benefit from the standard USB (USBTMC-compliant), RS-232, GPIB, and RS-485 interfaces supporting SCPI commands.
Features:
• Multi-ranging operation
• Compact, high density, 1U rackmount form factor
• 0-150 V Voltage and 0-30 A Current
• High programming and readback resolution
• Adjustable voltage rise and fall times
• Automatically recalculate voltage and current limits for each setting
• Sequence programming
• Store and recall up to 100 instrument settings
• Standard USB (USBTMC-compliant), RS-232, GPIB, and RS-485 interfaces supporting SCPI commands for remote control
• Analog interface with control and monitoring functions
• Remote sense
• Overvoltage protection (OVP), overpower protection (OPP), overtemperature protection (OTP), and key-lock function
• Softpanel for remote control, test sequence generation, and data logging. This software also integrates with Data Dashboard for LabVIEW apps enabling iOS, Android or Windows 8 compatible tablets or smart phones to remotely monitor select measurement indicators
